Rule 3745-40-04 | Biosolids classifications.
[Comment: For dates of non-regulatory government publications, publications of recognized organizations and associations, federal rules and federal statutory provisions referenced in this rule, see rule 3745-40-01 of the Administrative Code.]
(A) General requirements.
(1) Prior to beneficial use, sewage sludge shall be treated to achieve a biosolids classification in accordance with this rule.
| Biosolids classification1 | Requirements for pathogen reduction (P) | Additional requirements for EQ biosolids | Requirements for vector attraction reduction (VAR) | Requirements for metals concentration limits |
| B | Choose from P-1 to P-16 | Not applicable | Choose from VAR-1 to VAR-10 | Table D-1 of this rule, and as applicable table D-3 of this rule |
| Exceptional quality (EQ) | Choose from P-8 to P-16 | In accordance with paragraph (A)(2) of this rule | Choose from VAR-1 to VAR-8 | Table D-1 of this rule and table D-3 of this rule |
1Class B and exceptional quality biosolids shall meet the screening requirements in accordance with paragraph (E) of this rule.
(2) For exceptional quality biosolids, the following are required in addition to table A-1:
(a) Demonstrate one of the following microbial limits to achieve the necessary additional pathogen reduction:
(i) The density of fecal coliform in the sewage sludge is less than one thousand most probable number (mpn) per gram of total solids (dry weight basis).
(ii) The density of Salmonella sp. bacteria in the sewage sludge is less than three most probable number (mpn) per four grams of total solids (dry weight basis).
(iii) To meet the fecal coliform or Salmonella sp. bacteria requirement, the samples should be collected and analyzed close enough to the time of beneficial use to be reflective of the biosolids' current quality, but not so close that the results of the analysis are not available prior to beneficial use or distribution of the biosolids, thus making the biosolids representative of the biosolids leaving the treatment works. At a minimum, seven grab samples of the biosolids shall be taken and analyzed at least once per reporting period with all results meeting the limits listed in this paragraph.
(b) Meet the pathogen reduction alternative either prior to, or at the same time as, vector attraction reduction when using VAR-1 to VAR-5.
(3) Develop and maintain for a minimum of five years records in accordance with this rule and rule 3745-40-09 of the Administrative Code.
(4) Class B biosolids altered in any way, including by the addition of other materials, such as class B biosolids from another treatment works, shall undergo treatment following alteration to meet pathogen reduction and vector attraction reduction prior to beneficial use as class B biosolids.
[Comment: Other material does not include liming materials.]
(B) Pathogen reduction alternatives.
(1) Pathogen reduction alternative P-1: geometric mean of seven samples.
(a) To achieve pathogen reduction alternative P-1, the permittee shall:
(i) At a minimum, collect seven grab samples of the sewage sludge in accordance with a standard operating procedure developed under paragraph (C) of rule 3745-40-09 of the Administrative Code. Take sewage sludgesamples at least once per reporting period at various locations and depths, so as to be representative of biosolids leaving the facility. The director may require more than seven samples to be taken to ensure adequate representation.
(ii) Ensure that the geometric mean of the density of fecal coliform in the sewage sludge samples iseither of the following:
(a) Less than two million most probable number (mpn) per gram of total solids (dry weight basis).
(b) Less than two million colony forming units (cfu) per gram of total solids (dry weight basis).
[Comment: Seven samples need to be taken over a two-week period for facilities with continuous sludge processing. Example calculations may be found in "Pathogens and Vector Attraction in Sewage Sludge."]
(iii) Demonstrate that the sewage sludge has been stabilized through an actively mixed aerobic or anaerobic process or through lime stabilization.
(b) Record keeping requirements for pathogen reduction alternative P-1. All of the following records shall be maintained and submitted to the director or an authorized representative with the annual report:
(i) Written documentation that the sewage sludge has been stabilized through an actively mixed aerobic or anaerobic process or through lime stabilization. Examples of such documentation include mixing equipment design and operating parameters showing that sufficient air is provided to maintain solids in suspension and ensure complete mixing of the digester contents, calculated mean cell residence time in an anaerobic digester, or lime addition equipment design and operating parameters.
[Comment: Relevant information for design and operating parameters may be found in "Recommended Standards for Wastewater Facilities" or "Pathogens and Vector Attraction in Sewage Sludge" or in other technical manuals or literature.]
(ii) Analytical results, including lab reports or bench sheets, for the density of fecal coliform for each sample collected from the sewage sludge.
(iii) Calculations for the geometric mean of the density of fecal coliform for the sewage sludge.
(2) Pathogen reduction alternative P-2: aerobic digestion.
(a) To achieve pathogen reduction alternative P-2: aerobic digestion, the permittee shall:
(i) Agitate the sewage sludge with air or oxygen to maintain aerobic conditions for a specific mean cell residence time at a specific temperature.
(ii) Maintain values for the mean cell residence time and temperature between forty days at twenty degrees Celsius (sixty-eight degrees Fahrenheit) and sixty days at fifteen degrees Celsius (fifty-nine degrees Fahrenheit), where a minimum temperature of fifteen degrees Celsius is maintained at all times.
[Comment: The relevant equation for the mean cell residence time and pertinent information can be found in appendix E of " Pathogen and Vector Attraction in Sewage Sludge." To calculate the number of days of the mean cell residence time for temperatures between fifteen and twenty degrees Celsius (between fifty-nine and sixty-eight degrees Fahrenheit), use the following equation :
Time in days = 40 x 1.08 (20-T) (Where T is the temperature between fifteen and twenty degrees Celsius.) ]
(b) Recordkeeping requirements for pathogen reduction alternative P-2: aerobic digestion. Both of the following records shall be maintained and submitted to the director or an authorized representative with the annual report:
(i) The mean cell residence time of the sewage sludge in each aerobic digester.
(ii) The records showing the proper temperature was maintained during the mean cell residence time.
(3) Pathogen reduction alternative P-3: air drying.
(a) To achieve pathogen reduction alternative P-3: air drying , the permittee shall:
(i) Dry partially digested sewage sludge on sand beds or on paved or unpaved basins for a minimum of ninety days during which time the average ambient air temperature is greater than zero degrees Celsius (thirty-two degrees Fahrenheit) for at least sixty consecutive days.
[Comment: Partially digested sewage sludge means sewage sludge that has been partially stabilized through either an aerobic or anaerobic process.]
(ii) Expose the sewage sludge to the atmosphere for at least sixty consecutive days within the ninety-day period.
[Comment: When sewage sludge is covered by snow or being dewatered inside a geotextile bag, the sewage sludge is not considered to be exposed to the atmosphere.]
(iii) Return all leachate from the drying basins to the treatment process.
(b) Recordkeeping requirements for pathogen reduction alternative P-3: air drying. All of the following records shall be maintained and submitted to the director or an authorized representative with the annual report:
(i) Written documentation that the sewage sludge has been partially stabilized through an aerobic or anaerobic process or that the sewage sludge has been stabilized through an actively mixed aerobic or anaerobic process.
(ii) A description of the drying bed design, including the type of media being used, the number of drying beds available, the number of drying beds in use, and the dimensions of each drying bed.
(iii) The drying time in days for each drying bed in use.
(iv) The daily minimum temperature for each of the ninety days.
(4) Pathogen reduction alternative P-4: anaerobic digestion.
(a) To achieve pathogen reduction alternative P-4: anaerobic digestion, the permittee shall:
(i) Treat sewage sludge or biosolids in the absence of air for a specific mean cell residence time at a specific temperature. The sewage sludge or biosolids may be commingled with bulking agents or additives, as defined in rule 3745-560-02 of the Administrative Code, and feedstocks. Bulking agents, additives, or feedstocks shall be introduced prior to, or during the anaerobic digestion process.
(ii) Maintain values for the mean cell residence time and temperature between fifteen days at thirty-five to fifty-five degrees Celsius (between ninety-five and one hundred thirty-one degrees Fahrenheit) and sixty days at twenty degrees Celsius (sixty-eight degrees Fahrenheit), where a minimum temperature of twenty degrees Celsius (sixty-eight degrees Fahrenheit) is maintained at all times. To calculate the number of days of the mean cell residence time needed for temperatures between twenty and thirty degrees Celsius (between sixty-eight and ninety-five degrees Fahrenheit), the following equation may be used:
Time in days = 15+3 (35-T) (Where T is the temperature between twenty and thirty-five degrees Celsius.)
[Comment: The relevant equations for the mean cell residence time and pertinent information can be found in appendix D of "Pathogen and Vector Attraction in Sewage Sludge."
]
(b) Recordkeeping requirements for pathogen reduction alternative P-4: anaerobic digestion. All of the following records shall be maintained and submitted to the director or an authorized representative with the annual report:
(i) The mean cell residence time of sewage sludge in each digester averaged over the monitoring period.
(ii) The temperature records of sewage sludge in each digester averaged over the monitoring period.
(iii) The weight or volume and general counties of origin of all feedstocks, bulking agents and additives utilized in the anaerobic digestion process.
(5) Pathogen reduction alternative P-5: class B composting.
(a) To achieve pathogen reduction alternative P-5: class B composting, the permittee shall meet both of the following:
(i) Operate in accordance with the requirements of Chapters 3704. and 6111. of the Revised Code, section 3745.11 of the Revised Code and rules adopted there under. Such treatment works are not subject to the requirements in Chapter 3745-560 of the Administrative Code if all of the following conditions are met:
(a) The owner or operator of the treatment works is operating the treatment works in accordance with an NPDES permit issued in accordance with Chapter 6111. of the Revised Code.
(b) The owner or operator of the treatment works composts sewage sludge or biosolids exclusively with bulking agents or additives, as defined in rule 3745-560-02 of the Administrative Code.
(c) The owner or operator of the treatment works utilizes only sewage sludge, biosolids, yard waste, animal waste, food scraps, food waste or an alternative material that has been approved by the director or an authorized representative for use in the composting process.
(ii) Composting is accomplished through any of the following:
(a) In vessel composting, where all of the following apply:
(i) The temperature of the compost medium is maintained at forty degrees Celsius (one hundred four degrees Fahrenheit) or higher for five consecutive days throughout the entire composting medium.
(ii) For four consecutive hours during the five-day period, the temperature of the composting medium exceeds fifty-five degrees Celsius (one hundred thirty-one degrees Fahrenheit).
(iii) The temperature is measured at multiple points and at a range of depths throughout the composting medium and is recorded at the beginning of the compost process when the minimum temperature has been reached, at least once daily, at least once per hour during the four-hour period when the composting medium is above fifty-five degrees Celsius (one hundred thirty-one degrees Fahrenheit) and at the end of the five-day period.
(b) Aerated static pile composting, where all of the following apply:
(i) The temperature of the composting medium is maintained at forty degrees Celsius (one hundred four degrees Fahrenheit) or higher for five consecutive days throughout the entire composting medium.
(ii) For four consecutive hours during the five-day period, the temperature of the composting medium exceeds fifty-five degrees Celsius (one hundred thirty-one degrees Fahrenheit).
(iii) One foot or greater of an insulation material is placed over the surface of the aerated static pile to ensure that the entire composting medium achieves forty degrees Celsius (one hundred four degrees Fahrenheit) or higher. Finished compost can be used as insulation material to cover the aerated static pile provided it is exceptional quality biosolids.
(iv) The temperature is measured at multiple points and at a range of depths throughout the composting medium, including the toes of the pile, and is recorded at the beginning of the composting process, at least once daily, at least once per hour during the four-hour period that the composting medium is above fifty-five degrees Celsius (one hundred thirty-one degrees Fahrenheit) and at the end of the five-day period.
[Comment: It is recommended that a method be used that draws air through the composting medium rather than blowing air through the medium. Drawing air through the composting medium provides greater odor control because the compost air can be easily collected and then filtered or scrubbed.]
(c) Windrow composting, where all of the following apply:
(i) The temperature of the windrow of composting medium is maintained at forty degrees Celsius (one hundred four degrees Fahrenheit) or higher for a minimum of five consecutive days, except during active turning or mixing of the windrow.
(ii) For four consecutive hours during the five-day period, the temperature of the composting medium exceeds fifty-five degrees Celsius (one hundred thirty-one degrees Fahrenheit).
(iii) The windrow of composting medium is turned or mixed during the five-day period so that the entire compost medium has maintained a temperature of forty degrees Celsius (one hundred four degrees Fahrenheit) for a minimum of five days. The turning or mixing is done by a machine that moves the core of the composting material to the outside of the windrow and moves the outside compost material into the core of the windrow.
(iv) The temperature of the windrow is at or above forty degrees Celsius (one hundred four degrees Fahrenheit) within twenty-four hours after the turning or mixing of the windrow is complete.
(v) The temperature is measured at multiple points and at a range of depths throughout the composting medium, including the toes of the pile, and is recorded at the beginning of the composting process, at least once daily, at least once per hour during the four-hour period that the composting medium is above fifty-five degrees Celsius (one hundred thirty-one degrees Fahrenheit) and at the end of the five-day period.
[Comment: It is recommended that treatment works allow sewage sludge or biosolids to compost for a minimum of fourteen days for in-vessel composting, twenty-one days for static aerated pile composting, or thirty days for windrow composting to reduce volatile solids in the sewage sludge or biosolids. Sewage sludge or biosolids that are composted for the minimum amount of time by rule may still be odorous. Composting is generally considered complete when the temperature of the compost returns to ambient temperatures.]
(b) Recordkeeping requirements for pathogen reduction alternative P-5: composting. All of the following records shall be maintained and submitted to the director or an authorized representative with the annual report:
(i) A description of the composting method, including where the temperature is measured.
(ii) The weight or volume and origin of all materials, bulking agents, and additives utilized in the composting process.
(iii) For in-vessel composting, both of the following:
(a) The daily temperature records for each vessel at each sample location that documents that the sewage sludge was maintained at a temperature of forty degrees Celsius (one hundred four degrees Fahrenheit) for five days.
(b) The hourly readings for each vessel at each sample location showing that the temperature exceeded fifty-five degrees Celsius (one hundred thirty-one degrees Fahrenheit) for four consecutive hours.
(iv) For aerated static pile composting, both of the following:
(a) The daily temperature records for each aerated static pile at each sample location that documents that the sewage sludge was maintained at a temperature of forty degrees Celsius (one hundred four degrees Fahrenheit) for five days.
(b) The hourly readings for each aerated static pile at each sample location showing that the temperature exceeded fifty-five degrees Celsius (one hundred thirty-one degrees Fahrenheit) for four consecutive hours.
(v) For windrow composting, all of the following:
(a) The daily temperature records for each windrow at each sample location that documents that the sewage sludge was maintained at a temperature of forty degrees Celsius (one hundred four degrees Fahrenheit) for five days.
(b) The hourly readings for each windrow at each sample location showing that the temperature exceeded fifty-five degrees Celsius (one hundred thirty-one degrees Fahrenheit) for four consecutive hours.
(c) Records that indicate the day and the time of day each windrow was turned or mixed.
(6) Pathogen reduction alternative P-6: lime treatment.
(a) To achieve pathogen reduction alternative P-6: lime treatment, the permittee shall perform all of the following:
(i) Add sufficient lime to the sewage sludge to raise the pH to twelve after two hours of contact.
(ii) Provide sufficient mixing to ensure that the entire mass of sewage sludge comes into contact with the lime and achieves the minimum pH of twelve and measure the pH at several locations to ensure that the pH is raised throughout the sewage sludge.
(iii) Utilize best management procedures to minimize odors.
(b) Recordkeeping requirements for pathogen reduction alternative P-6: lime treatment. Records shall be maintained and submitted to the director or an authorized representative with the annual report that include all of the following:
(i) A description of how the pH is monitored throughout the sewage sludge and how the lime is mixed into the sewage sludge.
(ii) Records that initially document the pH of the sewage sludge once lime has been added and then documents the pH again two hours after the addition of the lime.
(iii) Records showing the amount of lime material that was added and when it was added, expressed in dry tons.
[Comment: A variety of lime stabilization processes are currently in use. The effectiveness of any lime stabilization process for controlling pathogens depends on maintaining the pH at levels that reduce microorganisms in the sewage sludge. Field experience has shown that the authorized beneficial use of lime stabilized material after the pH has dropped below 10.5 may, in some cases, create odor problems. Therefore, it is recommended that biosolids beneficial use take place while the pH remains elevated. If this is not possible, and odor problems develop, perform alternate management practices in the field, including injection or incorporation or top dressing the beneficially used biosolids with additional lime. Alternate management practices, if the biosolids have not yet left the treatment works, may include adding additional lime to maintain the elevated pH or additional treatment through drying or composting.]
(7) Pathogen reduction alternative P-7: equivalent process to significantly reduce pathogens.
(a) To achieve pathogen reduction alternative P-7: equivalent process to significantly reduce pathogens, the permittee shall treat sewage sludge to generate biosolids for beneficial use in a process that is equivalent to a process to significantly reduce pathogens, as determined by the director.
(b) Recordkeeping requirements for pathogen reduction alternative P-7: equivalent process to significantly reduce pathogens. Maintain the records of the operating parameters or pathogen levels, as necessary to demonstrate the equivalent process to significantly reduce pathogens and submit these records to the director or an authorized representative with the annual report.
(8) Pathogen reduction alternative P-8: time and temperature regime.
(a) To achieve pathogen reduction alternative P-8, the permittee shall maintain a temperature in the sewage sludge at a specific value for a specific time period, in accordance with the following:
(i) For sewage sludge with a per cent solids of seven per cent or higher, the temperature of the sewage sludge is fifty degrees Celsius (one hundred twenty-two degrees Fahrenheit) or higher, the time period is twenty minutes or longer and the temperature and time period is determined using equation number one, except when small particles of sewage sludge are heated by either warmed gases or an immiscible liquid. Equation number one is as follows:
D = 131,700,000/100.1400T (where D equals time in days and T equals temperature in degrees Celsius).
[Comment: The times and temperatures in table B-1 of this rule provide common durations for common temperatures, relevant to the requirements of paragraph (B)(8)(a)(i) of this rule.]
| Temperature in degrees Celsius | Temperature in degrees Fahrenheit | Duration in days | Duration in hours | Duration in minutes |
| 50 | 122 | 14 | -- | -- |
| 52 | 125.6 | 7 | -- | -- |
| 54 | 129.2 | 4 | -- | -- |
| 56 | 132.8 | 2 | -- | -- |
| 58 | 136.4 | -- | 24 | -- |
| 60 | 140 | -- | 13 | -- |
| 62 | 143.6 | -- | 7 | -- |
| 64 | 147.2 | -- | 4 | -- |
| 66 | 150.8 | -- | 2 | -- |
| 68 | 154.4 | -- | -- | 57 |
| 70 | 158 | -- | -- | 30 |
| 72 | 161.6 | -- | -- | 20 |
| Above 74 | Above 165.2 | -- | -- | 20 |
(ii) For sewage sludge with a per cent solids of seven per cent or higher and small particles of sewage sludge are heated by either warmed gases or an immiscible liquid, the temperature of the sewage sludge is fifty degrees Celsius (one hundred twenty-two degrees Fahrenheit) or higher, the time period is fifteen seconds or longer and the temperature and time period is determined using equation number one.
[Comment: The times and temperatures in table B-2 of this rule provide common durations for common temperatures, relevant to the requirements of paragraph (B)(8)(a)(ii) of this rule.]
| Temperature in degrees Celsius | Temperature in degrees Fahrenheit | Duration in days | Duration in hours | Duration in minutes | Duration in seconds |
| 50 | 122 | 14 | -- | -- | -- |
| 52 | 125.6 | 7 | -- | -- | -- |
| 54 | 129.2 | 4 | -- | -- | -- |
| 56 | 132.8 | 2 | -- | -- | -- |
| 58 | 136.4 | 1 | -- | -- | -- |
| 60 | 140 | -- | 13 | -- | -- |
| 62 | 143.6 | -- | 7 | -- | -- |
| 64 | 147.2 | -- | 4 | -- | -- |
| 66 | 150.8 | -- | 2 | -- | -- |
| 68 | 154.4 | -- | -- | 57 | -- |
| 70 | 158 | -- | -- | 30 | -- |
| 72 | 161.6 | -- | -- | 16 | -- |
| 74 | 165.2 | -- | -- | 9 | -- |
| 76 | 168.8 | -- | -- | 5 | -- |
| 78 | 172.4 | -- | -- | 3 | -- |
| 80 | 176 | -- | -- | 2 | -- |
| 82 | 179.6 | -- | -- | -- | 38 |
| 84 | 183.2 | -- | -- | -- | 20 |
| Above 84 | Above 183.2 | -- | -- | -- | 15 |
(iii) When the per cent solids of the sewage sludge is less than seven per cent and the time period is at least fifteen seconds, but less than thirty minutes, the temperature and time period is to be determined using equation number one.
[Comment: Times and temperatures in table B-3 of this rule provide common durations for common temperatures, relevant to the requirements of paragraph (B)(8)(a)(iii) of this rule.]
| Temperature in degrees Celsius | Temperature in degrees Fahrenheit | Duration in days | Duration in hours | Duration in minutes | Duration in seconds |
| 70 | 158 | -- | -- | 30 | -- |
| 72 | 161.6 | -- | -- | 15 | -- |
| 74 | 165.2 | -- | -- | 9 | -- |
| 76 | 168.8 | -- | -- | 5 | -- |
| 78 | 172.4 | -- | -- | 3 | -- |
| 80 | 176 | -- | -- | 2 | -- |
| 82 | 179.6 | -- | -- | -- | 38 |
| 84 | 183.2 | -- | -- | -- | 20 |
| Above 84 | Above 183.2 | -- | -- | -- | 15 |
(iv) When the per cent solids of the sewage sludge is less than seven per cent, the temperature of the sewage sludge is fifty degrees Celsius (one hundred twenty-two degrees Fahrenheit) or higher, and the time period is thirty minutes or longer, the temperature and time period is to be determined using equation number two. Equation number two is as follows:
D = 50,070,000/100.1400T (Where D equals time in days and T equals temperature in degrees Celsius.)
[Comment: The times and temperatures in table B-4 of this rule provide common durations for common temperatures, relevant to the requirements in paragraph (B)(8)(a)(iv) of this rule.]
| Temperature in degrees Celsius | Temperature in degrees Fahrenheit | Duration in days | Duration in hours | Duration in minutes |
| 50 | 122 | 5 | -- | -- |
| 52 | 125.6 | 3 | -- | -- |
| 54 | 129.2 | 2 | -- | -- |
| 56 | 132.8 | -- | 18 | -- |
| 58 | 136.4 | -- | 10 | -- |
| 60 | 140 | -- | 5 | -- |
| 62 | 143.6 | -- | 3 | -- |
| 64 | 147.2 | -- | 2 | -- |
| 66 | 150.8 | -- | -- | 42 |
| 68 | 154.4 | -- | -- | 30 |
| Above 70 | Above 158 | -- | -- | 30 |
(b) Recordkeeping requirements for pathogen reduction alternative P-8: time and temperature regime. All of the following records shall be maintained and submitted to the director or an authorized representative with the annual report:
(i) Analytical results for density of fecal coliform bacteria expressed as the most probable number (mpn) per gram of total solids in dry weight basis, or the density of Salmonella sp. bacteria expressed as mpn per four grams of total solids in dry weight basis.
(ii) The sewage sludge temperature.
(iii) The duration, in days, hours, minutes and seconds, as applicable, that the temperature was maintained.
(iv) Analytical results for per cent solids of the sewage sludge or biosolids treated in the process.
(9) Pathogen reduction alternative P-9: high pH and high temperature process.
(a) To achieve pathogen reduction alternative P-9, the permittee shall complete all of the following:
(i) Ensure that the pH of the sewage sludge is raised to above twelve and remains above twelve for at least seventy-two hours.
(ii) Provide sufficient mixing to ensure that the entire mass of sewage sludge comes into contact with the lime to meet the minimum pH of twelve and measure the pH at several locations to ensure that the pH is raised throughout the sewage sludge.
(iii) Ensure that the temperature of the sewage sludge is above fifty-two degrees Celsius (one hundred twenty-five and six tenths degrees Fahrenheit) for at least twelve hours during the period that the pH of the sewage sludge is above twelve.
(iv) Ensure that at the end of the seventy-two-hour period during which the pH of the sewage sludge is above twelve, that the sewage sludge is air dried to a per cent solids of greater than fifty per cent.
(b) Recordkeeping requirements for pathogen reduction alternative P-9: high pH and high temperature process. All of the following records shall be maintained and submitted to the director or an authorized representative with the annual report:
(i) Analytical results for density of fecal coliform bacteria expressed as the most probable number (mpn) per gram of total solids in dry weight basis, or the density of Salmonella sp. bacteria expressed as mpn per four grams of total solids in dry weight basis.
(ii) Records of the sewage sludge pH at start-up, at twenty-four hours, at forty-eight hours and at seventy-two hours.
(iii) The hourly sewage sludge temperature for the twelve hours that the temperature is to be maintained above fifty-two degrees Celsius (one hundred twenty-five and six tenths degrees Fahrenheit).
(iv) The per cent solids of the sewage sludge after air drying.
(v) Records showing the amount of lime material that was added and when it was added, expressed in dry tons.
(vi) A description of how the pH and temperature are maintained throughout the sewage sludge.
(10) Pathogen reduction alternative P-10: exceptional quality composting.
(a) To achieve pathogen reduction alternative P-10, the permittee shall:
(i) Operate in accordance with the requirements of Chapters 3704. and 6111. of the Revised Code, section 3745.11 of the Revised Code and any rules adopted there under. Such treatment works are not subject to the requirements of Chapter 3745-560 of the Administrative Code if all the following conditions are met:
(a) The owner or operator of the treatment works is operating the treatment works in accordance with an NPDES permit issued in accordance with Chapter 6111. of the Revised Code.
(b) The owner or operator of the treatment works composts sewage sludge or biosolids exclusively with bulking agents or additives, as defined in rule 3745-560-02 of the Administrative Code, or alternative bulking agents or additives that have been approved by the director or an authorized representative.
(c) The owner or operator of the treatment works utilizes only sewage sludge, biosolids, yard waste, animal waste, food scraps, food waste or an alternative material that has been approved by the director or an authorized representative for use in the composting process.
(ii) Accomplish composting through any of the following methods:
(a) In-vessel composting, where both of the following conditions are met:
(i) The temperature of the composting medium is maintained at fifty-five degrees Celsius (one hundred thirty-one degrees Fahrenheit) or higher for seventy-two hours throughout the entire composting medium.
(ii) The temperature is measured at multiple points and at a range of depths throughout the composting medium and is recorded, at a minimum, at the beginning of the composting process, at twenty-four hours, at forty-eight hours and at seventy-two hours.
(b) Aerated static pile composting, where all of the following conditions are met:
(i) The temperature of the composting medium is maintained at fifty-five degrees Celsius (one hundred thirty-one degrees Fahrenheit) or higher for seventy-two consecutive hours throughout the entire composting medium.
(ii) One foot or greater of an insulation material is placed over the surface of the aerated static pile to help ensure that the entire composting medium achieves fifty-five degrees Celsius (one hundred thirty-one degrees Fahrenheit) or higher. Finished compost can be used as an insulation material to cover the aerated static pile provided it is exceptional quality biosolids.
(iii) The temperature is measured at multiple points and at a range of depths throughout the composting medium including the toes of the piles, and is recorded, at a minimum, at the beginning of the composting process and at twenty-four, forty-eight and seventy-two hours at a minimum.
[Comment: It is recommended that a method be used that draws air through the composting medium rather than blowing air through the medium. Drawing air through the composting medium provides greater odor control because the air can be easily collected and then filtered or scrubbed.]
(c) Windrow composting, where all of the following conditions are met:
(i) The temperature of the composting medium is maintained at fifty-five degrees Celsius (one hundred thirty-one degrees Fahrenheit) or higher for a minimum of fifteen consecutive days, except during active turning or mixing of the windrow.
(ii) The windrow of composting medium is turned or mixed at seventy-two hour intervals during the fifteen-day period, with a minimum of five turnings or mixings.
(iii) The turning or mixing is done by a machine that moves the core of the compost material to the outside of the windrow and moves the outside compost material into the core of the windrow.
(iv) The core temperature of the windrow is at or above fifty-five degrees Celsius (one hundred thirty-one degrees Fahrenheit) within twenty-four hours after each turning or mixing of the windrow is complete.
(v) The temperature is measured in the core of the windrow at various locations along the length of the windrow and is recorded at the same time daily, at a minimum, throughout the fifteen-day period.
[Comment: To reduce volatile solids, it is recommended that in-vessel composting and aerated static pile be conducted for a minimum of fourteen days and that windrow composting be conducted for a minimum of fifteen days. Sewage sludge or biosolids that are composted for the minimum amount of times may still be odorous.]
(b) Recordkeeping requirements for pathogen reduction alternative P-10: composting. All of the following records shall be maintained and submitted to the director or an authorized representative with the annual report:
(i) Analytical results for density of fecal coliform bacteria expressed as the most probable number (mpn) per gram of total solids in dry weight basis, or the density of Salmonella sp. bacteria expressed as mpn per four grams of total solids in dry weight basis.
(ii) A description of the composting method, including where the temperature was measured.
(iii) The weight or volume and origin of all materials, bulking agents and additives utilized in the composting process.
(iv) Records documenting that the temperature was maintained at or above fifty-five degrees Celsius (one hundred thirty-one degrees Fahrenheit) for each sampling location for:
(a) Three days for either in-vessel or aerated static pile composting.
(b) Fifteen days for windrow composting.
(v) For windrow composting , both of the following:
(a) Records documenting the compost pile was turned or mixed at least five times during the fifteen-day period.
(b) Records that indicate the day and the time of day each windrow was turned or mixed.
(11) Pathogen reduction alternative P-11: heat drying.
(a) To achieve pathogen reduction alternative P-11, the permittee shall dry the sewage sludge by direct or indirect contact with hot gases to increase the sewage sludge to a per cent solids content of at least ninety per cent, where either the temperature of the sewage sludge particles exceeds eighty degrees Celsius (one hundred seventy-six degrees Fahrenheit) or the wet bulb temperature of the gas in contact with the sewage sludge as the sewage sludge leaves the dryer exceeds eighty degrees Celsius (one hundred seventy-six degrees Fahrenheit).
(b) Recordkeeping requirements for pathogen reduction alternative P-11: heat drying. All of the following records shall be maintained and submitted to the director or an authorized representative with the annual report:
(i) Analytical results for density of fecal coliform bacteria expressed as the most probable number (mpn) per gram of total solids in dry weight basis, or the density of Salmonella sp. bacteria expressed as mpn per four grams of total solids in dry weight basis.
(ii) The per cent solids of the dried sewage sludge.
(iii) Records documenting that the temperature of the sewage sludge particles or the wet bulb temperature of exit gas exceeds eighty degrees Celsius (one hundred seventy-six degrees Fahrenheit).
(12) Pathogen reduction alternative P-12: thermophilic aerobic digestion.
(a) To achieve pathogen reduction alternative P-12, the permittee shall agitate the liquid sewage sludge with air or oxygen to maintain aerobic conditions, where the mean cell residence time is ten days and the temperature, which is measured at least once per day, is between fifty-five and sixty degrees Celsius (one hundred thirty-one degrees to one hundred forty degrees Fahrenheit).
(b) Recordkeeping requirements for pathogen reduction alternative P-12: thermophilic aerobic digestion. All of the following records shall be maintained and submitted to the director or an authorized representative with the annual report:
(i) Analytical results for density of fecal coliform bacteria expressed as the most probable number (mpn) per gram of total solids in dry weight basis, or the density of Salmonella sp. bacteria expressed as mpn per four grams of total solids in dry weight basis.
(ii) Records documenting the temperature was maintained at fifty-five to sixty degrees Celsius (one hundred thirty-one degrees to one hundred forty degrees Fahrenheit) in each digester.
(iii) Records documenting the mean cell residence time was met in each digester.
(13) Pathogen reduction alternative P-13: beta ray irradiation.
(a) To achieve pathogen reduction alternative P-13, the permittee shall irradiate the sewage sludge with beta rays from an accelerator at dosages of at least one megarad at room temperature (approximately twenty degrees Celsius or sixty-eight degrees Fahrenheit).
(b) Recordkeeping requirements for pathogen reduction alternative P-13: beta ray irradiation. All of the following records shall be maintained and submitted to the director or an authorized representative with the annual report:
(i) Analytical results for density of fecal coliform bacteria expressed as the most probable number (mpn) per gram of total solids in dry weight basis, or the density of Salmonella sp. bacteria expressed as mpn per four grams of total solids in dry weight basis.
(ii) The beta ray dosage.
(iii) The ambient room temperature records.
(14) Pathogen reduction alternative P-14: gamma ray irradiation.
(a) To achieve pathogen reduction alternative P-14, the permittee shall irradiate the sewage sludge with gamma rays from certain isotopes, such as \60\cobalt and \137\cesium, at dosages of at least one megarad at room temperature (approximately twenty degrees Celsius or sixty-eight degrees Fahrenheit).
(b) Recordkeeping requirements for pathogen reduction alternative P-14: gamma ray irradiation. All of the following records shall be maintained and submitted to the director or an authorized representative with the annual report:
(i) Analytical results for density of fecal coliform bacteria expressed as the most probable number (mpn) per gram of total solids in dry weight basis, or the density of Salmonella sp. bacteria expressed as mpn per four grams of total solids in dry weight basis.
(ii) Documentation of the gamma ray isotope uses.
(iii) The gamma ray dosage.
(iv) The ambient room temperature records.
(15) Pathogen reduction alternative P-15: pasteurization.
(a) To achieve pathogen reduction alternative P-15, the permittee shall maintain the temperature of the sewage sludge at seventy degrees Celsius (one hundred fifty-eight degrees Fahrenheit) or higher for thirty minutes or longer and use a device to monitor the temperatures to ensure that the temperature of the sewage sludge does not fall below seventy degrees Celsius (one hundred fifty-eight degrees Fahrenheit) during the thirty-minute period.
(b) Recordkeeping requirements for alternative P-15: pasteurization. Both of the following records shall be maintained and submitted to the director or an authorized representative with the annual report:
(i) Analytical results for density of fecal coliform bacteria expressed as the most probable number (mpn) per gram of total solids in dry weight basis, or the density of Salmonella sp. bacteria expressed as mpn per four grams of total solids in dry weight basis.
(ii) Records documenting that the temperature was maintained at or above seventy degrees Celsius (one hundred fifty-eight degrees Fahrenheit) or higher for at least thirty minutes throughout the sewage sludge.
(16) Pathogen reduction alternative P-16: equivalent process to further reduce pathogens.
(a) To achieve pathogen reduction alternative P-16, the permittee shall treat the sewage sludge in a manner that is equivalent to a process to further reduce pathogens, as determined by the director.
(b) Recordkeeping requirement for pathogen reduction alternative P-16: equivalent process to further reduce pathogens. Maintain and submit both of the following records to the director or an authorized representative with the annual report:
(i) Analytical results for density of fecal coliform bacteria expressed as the most probable number (mpn) per gram of total solids in dry weight basis, or the density of Salmonella sp. bacteria expressed as mpn per four grams of total solids in dry weight basis.
(ii) Operating parameters or pathogen levels, as necessary, to demonstrate that the equivalent process to further reduce pathogens has been achieved.
(C) Vector attraction reduction options.
(1) Vector attraction reduction option VAR-1: thirty-eight per cent volatile solids reduction.
(a) To achieve option VAR-1, the permittee shall reduce the mass of volatile solids in the sewage sludge by a minimum of thirty-eight per cent.
[Comment: Calculations for determining the volatile solids reduction may be found in "Pathogens and Vector Attraction in Sewage Sludge."]
(b) Recordkeeping requirements for vector attraction reduction option VAR-1: thirty-eight per cent volatile solids reduction. Both of the following records shall be maintained and submitted to the director or an authorized representative with the annual report:
(i) The volatile solids concentration of the raw sewage sludge and the final sewage sludge and the location of each sample taken.
(ii) The calculations showing that thirty-eight per cent volatile solids reduction was achieved.
(2) Vector attraction reduction option VAR-2: bench scale anaerobic digestion.
(a) To achieve option VAR-2 when the thirty-eight per cent volatile solids reduction requirement in paragraph (C)(1)(a) of this rule cannot be met for an anaerobically digested sewage sludge, the permittee can demonstrate vector attraction reduction by both of the following:
(i) Digesting a portion of the previously digested sewage sludge anaerobically in the laboratory in a bench scale unit for at least forty additional days at a temperature between thirty and thirty-seven degrees Celsius (eighty-six to ninety-eight degrees Fahrenheit).
(ii) Showing that at the end of the forty days the volatile solids in the sewage sludge at the beginning of that period is reduced by less than seventeen per cent.
(b) Recordkeeping requirements for vector attraction reduction option VAR-2: bench scale anaerobic digestion. All of the following records shall be maintained and submitted to the director or an authorized representative with the annual report:
(i) A description of the bench scale digester.
(ii) The time in days that the sample was further digested in the bench scale digester.
(iii) Daily temperature records.
(iv) The volatile solids concentration of the sewage sludge before and after the bench scale digestion.
(3) Vector attraction reduction option VAR-3: bench scale aerobic digestion.
(a) To achieve option VAR-3 when the thirty-eight per cent volatile solids reduction requirement in paragraph (C)(1)(a) of this rule cannot be met for an aerobically digested sewage sludge, the permittee can demonstrate vector attraction reduction by both of the following:
(i) Digesting a portion of the previously digested sewage sludge that has a per cent solids of two per cent or less aerobically in the laboratory in a bench-scale unit for thirty additional days at twenty degrees Celsius (sixty-eight degrees Fahrenheit).
(ii) Showing that at the end of the thirty days the volatile solids in the sewage sludge at the beginning of that period is reduced by less than fifteen per cent.
(b) Recordkeeping requirements for vector attraction reduction option VAR-3: bench scale aerobic digestion. All of the following records shall be maintained and submitted to the director or an authorized representative with the annual report:
(i) A description of the bench scale digester.
(ii) The time in days that the sample was further digested in the bench scale digester.
(iii) Daily temperature records.
(iv) The volatile solids concentration of the sewage sludge before and after the bench scale digestion.
(4) Vector attraction reduction option VAR-4: specific oxygen uptake rate (SOUR) test.
(a) To achieve option VAR-4, the permittee shall demonstrate the following:
(i) Sewage sludge is treated in an aerobic process at temperatures between ten and thirty degrees Celsius (between fifty and eighty-six degrees Fahrenheit).
(ii) The specific oxygen uptake rate is equal to or less than 1.5 milligrams of oxygen per hour per gram of total solids (dry weight basis) at a temperature of twenty degrees Celsius (sixty-eight degrees Fahrenheit).
(iii) The temperature of the sewage sludge to be tested is maintained at the same temperature as the sewage sludge was in the digester.
(iv) The SOUR testing is conducted routinely so that sufficient data are available to indicate average performance.
(b) Recordkeeping requirements for vector attraction reduction option VAR-4: specific oxygen uptake rate (SOUR) test. All of the following records shall be maintained and submitted to the director or an authorized representative with the annual report:
(i) Dissolved oxygen readings for each sewage sludge sample taken every minute over a fifteen-minute interval.
(ii) Calculations and temperature records showing that each test was corrected to twenty degrees Celsius (sixty-eight degrees Fahrenheit).
[Comment: To adjust the specific oxygen uptake rate to twenty degrees Celsius, use the following equation:]
(iii) Total solids for the sewage sludge sample.
(iv) The SOUR calculations for each test.
[Comment: A SOUR calculation worksheet and an example SOUR standard operating procedure are both available online at the Ohio environmental protection agency biosolids webpage .]
(5) Vector attraction reduction option VAR-5: aerobic process time and temperature treatment.
(a) To achieve option VAR-5, the permittee shall demonstrate that sewage sludge is treated in an aerobic process for fourteen days or longer, during which time the temperature of the sewage sludge is higher than forty degrees Celsius (one hundred four degrees Fahrenheit) and the average temperature of the sewage sludge is higher than forty-five degrees Celsius (one hundred thirteen degrees Fahrenheit).
(b) Recordkeeping requirements for vector attraction reduction option VAR-5: aerobic process time and temperature regime. Both of the following records shall be maintained and submitted to the director or an authorized representative with the annual report:
(i) The sewage sludge detention time in the aerobic digester or composting process.
(ii) Temperature records showing that the average temperature was above forty-five degrees Celsius (one hundred thirteen degrees Fahrenheit) and the minimum temperature was above forty degrees Celsius (one hundred four degrees Fahrenheit) for fourteen consecutive days.
(6) Vector attraction reduction option VAR-6: lime treatment.
(a) To achieve option VAR-6, the permittee shall raise the pH of the sewage sludge to twelve or higher by lime addition and, without the addition of more lime, maintain the pH at twelve or higher for two hours and then remain at 11.5 or higher for an additional twenty-two hours.
(b) Recordkeeping requirements for vector attraction reduction option VAR-6: lime treatment. All of the following records shall be maintained and submitted to the director or an authorized representative with the annual report:
(i) A narrative description of how the pH was monitored throughout the material for the applicable time period.
(ii) Records indicating that the pH was maintained at or above twelve for two hours and at or above 11.5 for an additional twenty-two hours.
(iii) The number of dry tons of the lime material that was added.
(7) Vector attraction reduction option VAR-7: greater than or equal to seventy-five per cent solids.
(a) To achieve option VAR-7, the permittee shall demonstrate that the per cent solids of sewage sludge that does not contain unstabilized solids generated in a primary wastewater treatment process is equal to or greater than seventy-five per cent based on the moisture content and total solids prior to mixing with other materials.
(b) Recordkeeping requirements for vector attraction reduction option VAR-7: greater than or equal to seventy-five per cent solids. Both of the following records shall be maintained and submitted to the director or an authorized representative with the annual report:
(i) Results of per cent solids tests.
(ii) Records showing that the sewage sludge has been stabilized.
(8) Vector attraction reduction option VAR-8: greater than or equal to ninety per cent solids.
(a) To achieve option VAR-8, the permittee shall demonstrate that the per cent solids of sewage sludge that contains unstabilized solids generated in a primary wastewater treatment process is equal to or greater than ninety per cent based on the moisture content and total solids prior to mixing with other materials . Measures for proper storage to avoid a decrease in per cent solids and to prevent odors shall be taken.
(b) Recordkeeping requirements for vector attraction reduction option VAR-8: greater than or equal to ninety per cent solids. The results of the per cent solids tests on a dry weight basis shall be maintained and submitted to the director or an authorized representative with the annual report.
(9) Vector attraction reduction option VAR-9: biosolids are injected below the surface of the authorized beneficial use site.
(a) To achieve option VAR-9, the permittee or beneficial user shall inject biosolids below the surface of the authorized beneficial use site, where no significant amount of biosolids is present on the surface of the authorized beneficial use site within one hour after the biosolids are injected.
(b) Recordkeeping requirements for vector attraction reduction option VAR-9: biosolids are injected below the surface of the authorized beneficial use site. Both the description of how injection was performed and the beneficial user signed statement, in accordance with rule 3745-40-09 of the Administrative Code, shall be maintained and submitted to the director or an authorized representative with the annual report.
(10) Vector attraction reduction option VAR-10: immediate incorporation of biosolids.
(a) To achieve option VAR-10, the permittee or beneficial user shall incorporate biosolids into the soil at a minimum depth of four inches or greater within six hours of delivery to the authorized beneficial use site, unless otherwise specified by the director.
(b) Recordkeeping requirements for vector attraction reduction option VAR-10: immediate incorporation of biosolids. The description of when and how immediate incorporation was performed, and the beneficial user signed statement , in accordance with rule 3745-40-09 of the Administrative Code, shall be maintained and submitted to the director or an authorized representative with the annual report.
(D) Metals concentration limits.
(1) No person shall beneficially use biosolids if any monitoring result indicates that a pollutant concentration exceeds the pollutant ceiling concentration listed in table D-1 of this rule.
[Comment: If more than one monitoring event occurs for the pollutants listed in table D-1 of this rule then all monitoring results shall show pollutant levels below the pollutant ceiling concentrations listed in table D-1 of this rule. Monitoring results cannot be averaged to show that pollutant levels are below the pollutant ceiling concentrations listed in table D-1 of this rule.]
(2) If a monitoring result indicates that a pollutant exceeds the pollutant ceiling concentrations listed in table D-1 of this rule, a permittee shall either dispose of the sewage sludge within a landfill or return the sewage sludge to the initial stage of the sewage sludge treatment train. If the permittee returns the sewage sludge to the sewage sludge treatment train, monitoring shall be repeated and the results shall show that pollutants do not exceed the pollutant ceiling concentrations listed in table D-1 of this rule before biosolids are removed from the treatment works for beneficial use.
(3) No person shall beneficially use biosolids at an authorized beneficial use site subject to the cumulative pollutant loading rates established in table D-2 of this rule if any of the cumulative pollutant loading rates in table D-2 of this rule have been reached at the authorized beneficial use site.
(4) Biosolids that exceed the pollutant reporting period average concentrations in table D-3 of this rule and do not exceed the pollutant ceiling concentrations in table D-1 of this rule are subject to the cumulative pollutant loading rates in table D-2 of this rule. Before class B biosolids subject to the cumulative pollutant loading rates in table D-2 of this rule are applied at an authorized beneficial use site in Ohio, the person who proposes to beneficially use the class B biosolids shall contact the Ohio environmental protection agency division of surface water to determine whether class B biosolids subject to the cumulative pollutant loading rates in this rule have been beneficially used at the authorized beneficial use site since July 20, 1993.
(a) If beneficial use of class B biosolids subject to the cumulative pollutant loading rates has not occurred since July 20, 1993, the cumulative amount for each pollutant listed in this rule may be applied at the authorized beneficial use site in accordance with this chapter.
(b) If class B biosolids subject to the cumulative pollutant loading rates have been beneficially used at the authorized beneficial use site since July 20, 1993, and the cumulative amount of each pollutant beneficially used at the authorized beneficial use site since that date is known, the cumulative amount of each pollutant applied at the authorized beneficial use site shall be used to determine the additional amount of each pollutant that can be applied at the authorized beneficial use site in accordance with this chapter.
(c) If class B biosolids subject to the cumulative pollutant loading rates have been beneficially used at the authorized beneficial use site since July 20, 1993, and the cumulative amount of each pollutant applied at the authorized beneficial use site since that date is not known, an additional amount of each pollutant shall not be applied at the authorized beneficial use site.
(5) Any person who beneficially uses class B biosolids subject to the cumulative pollutant loading rates in this rule at an authorized beneficial use site in Ohio shall provide written notice to the appropriate Ohio environmental protection agency district office prior to initial beneficial use of class B biosolids at the authorized beneficial use site. The Ohio environmental protection agency shall retain and provide access to the notice. The notice is to include both of the following:
(a) The Ohio EPA site number of the authorized beneficial use site.
(b) The name, address, telephone number and NPDES permit number of the generator of the class B biosolids.
| Pollutant | Pollutant ceiling concentration limit (milligrams per kilogram dry weight basis) |
| Arsenic | 75 |
| Cadmium | 85 |
| Copper | 4300 |
| Lead | 840 |
| Mercury | 57 |
| Molybdenum | 75 |
| Nickel | 420 |
| Selenium | 100 |
| Zinc | 7500 |
| Pollutant | Pollutant cumulative pollutant load rates (pounds per acre) |
| Arsenic | 36.6 |
| Cadmium | 34.8 |
| Copper | 1339.9 |
| Lead | 267.9 |
| Mercury | 15.2 |
| Nickel | 375.1 |
| Selenium | 89.3 |
| Zinc | 2500.4 |
| Pollutant | Pollutant reporting period average concentration limit (milligrams per kilogram dry weight basis) |
| Arsenic | 41 |
| Cadmium | 39 |
| Copper | 1500 |
| Lead | 300 |
| Mercury | 17 |
| Nickel | 420 |
| Selenium | 100 |
| Zinc | 2800 |
(E) Screening requirements for biosolids.
(1) Foreign/inert matter is considered solid waste and is excluded from this chapter. Foreign/inert matter should be disposed of within a licensed landfill.
(2) Prior to the beneficial use of biosolids, influent wastewater and septage, or sewage sludge at a treatment works shall be treated by a process such as physical screening or another method to significantly remove foreign/inert matter. Meeting this requirement may be accomplished by any of the following:
(a) Screening influent wastewater and influent septage through a bar screen with a maximum aperture of five-eighths inch (1.59 centimeters).
(b) Screening all biosolids through a bar screen with a maximum aperture of five-eighths inch (1.59 centimeters) prior to beneficial use.
(c) Obtaining approval from the director for an alternative method that achieves a removal rate equal to or greater than that achieved by the screening standards in paragraph (E)(2)(a) or (E)(2)(b) of this rule.
Last updated March 2, 2026 at 8:32 AM
Supplemental Information
